A20B-2900-0701 Fanuc SRAM Module 128KB

Fanuc memory board type FANUC SRAM Module reference FANUC A20B-2900-0701 for sale online on Cnc-shopping.com. This is a FANUC SMD PCB type File SRAM Module 128KB. This module SRAM 128KB will help you to replace a defective memory pcb or increase your memory size on your FANUC 15B CNC Control. The SMD module FANUC A20B-2900-0701 comes with a warranty.

Where components are to be placed, the printed circuit board has flat, usually tin-lead, silver, or gold plated copper pads without holes, called solder pads. Solder paste, a sticky mixture of flux and tiny solder particles, is first applied to all the solder pads with a stainless steel or nickel stencil using a screen printing process. After screen printing, the boards then proceed to the pick-and-place machines, where they are placed on a conveyor belt. The components to be placed on the boards are usually delivered to the production line in either paper/plastic tapes wound on reels or plastic tubes. Some large integrated circuits are delivered in static-free trays. Numerical control pick-and-place machines remove the parts from the tapes, tubes or trays and place them on the PCB. FANUC A20B-2900-0701

How do I replace or install a FANUC SMD module?
- Remove: Pull the 2 plastic catches outwards from the module base, then pull the SMD module upwards.
- Insert: Insert the new module diagonally with side B (Side-B) facing outwards, while pushing the top board of the module until it locks into place.
